Hardware
| CPU |
ARM Cortex A73 Octa --core ( 2.0GHz) |
| GPU |
Arm Mali--G72 MP3 |
| RAM |
8G |
| Internal Memory |
128G |
| External Memory |
Micro SD card ( T-FLASH card), max 256GB |
| Main Camera |
13.0MP(AF) with flash led |
| Sub Camera |
N/A |
| Battery |
5000mAh |
| Display |
4.5 inch IPS/AFFS 960*540 QHD industrial 500nit Sunlight Readable |
| Touch Panel |
Capacitive/frosted tempered film supports glove touch/spray/active capacitive pen |
Data capture
| Scanning Engine |
Honeywell EX30 long-distance 1D/2D scan engin |
IO/Sensor/Navigation
| SIM Card |
1.8/3.3V SIM card |
| TF Card |
Micro SD card ( T-FLASH card) ;max 256GB |
| Headphone |
3.5mm (CTIA） |
| Charging interface |
Type-C & 2pin pogo pin |
| Data interface |
USB Type-C(OTG)*1 |
| Gravity sensor |
support |
| Direction Sensor |
support |
| Magnetic Field Sensor |
support |
| Gyro sensor |
support |
| Rotation Vector |
support |
| Light-sensor |
support |
| Acceleration sensor |
support |
| Charger |
5.0V 2A-10W |
| Navigation |
GPS+Beidou+Glonass+AGPS+SBAS （EPO 2.5m） |
Appearance
| Size |
197*92*45mm（L×W×H） |
| Weight |
420g |
| Color & Material |
Gray（PC+ABS） |
Communications & Networking
| Phone Call |
GSM /WCDMA/CDMA 1X/VoLTE |
| 2G |
GSM/CDMA 1X/EDGE/GPRS/WAP |
| 2G Band |
GSM（B2/3/5/8） |
| 3G |
WCDMA 3.75G (HSDPA+ 42.2Mbps, HSUPA+ 11.5Mbps),EVDO |
| 3G Band |
WCDMA（B1/2/5/8）,Evdo: BC0/BC1 CDMA: BC0/BC1 |
| 4G |
FDD: 150Mbps down, 50Mbps UP TDD: 150Mbps downlink , 50Mbps uplink |
| 4G Band |
TD-LTE（B38/39/40/41）；FDD LTE（B1,B2,B3,B4,B5,B7,B8,B12,B17,B20,B28) |
| WI-FI |
Dual-band (2.4GHz/5Ghz) single stream 802.11 a/b/g/n/ac |
| Bluetooth |
4.2 Low Energy (LE) |
Industrial & Reliability Design
| Shake-proof |
1-19Hz/1.0mm; 19-200Hz/1.0g |
| Dropproof /IK |
MIL-STD-810G/Method516.6/Procedure IV & Touch Panel IK05 |
| Waterproof |
Class 6 ( IEC 60529 ) |
| Dustproof |
Class 6 ( IEC 60529 ) |
| Reliability |
MTBF>5000h；MTTR<0.5h |
| Operating temperature |
-10°C to 50°C |
| Storage Temperature |
-40°C to 80°C |
| RH |
5% to 95% (No condensation) |
| Operating Altitude |
Max: 4,500 m（15,000 feet） |
Certification/OS/Software
| Certification |
3C /FCC/CE/ROHS/IP66（IEC 60529） |
| Language |
English, Spanish, Portuguese (Brazil), Portuguese (Portugal), Italian, German, Dutch,French, Polish,Romanian, Turkish, Russian, Arabic, Indonesian, Malay, Thai, Vietnamese,Hindi, Hebrew, Simplified， Chinese,Chinese Traditional,etc |
| OS |
Android 10.0 / 11.0 |
Package/Warranty terms/OEM
| Warranty |
24 months |
| OEM/ODM |
Support |
| Package |
USB cable/Charger 5V 2A/Introduction manual/Screen protector/Packing box（Can be customized logo）/Aircraft box/Toolkit（optional） |
1D/2D Barcode Scan Engine
| 1D/2D Barcode |
10CM-30M Extended FlexRange Sensor Tecchnology: global shutter Resoluyion: 1280*800 pixels Frames per second: white LED Aimer: laser pointer(dot) Motion Tolerance: near(up to 6 m/s [19.7 ft/s] Far(up to 0,9 m/s [3.0 ft/s] Field of view: Near(horizontal: 42.5° ±2°, vertical: 27.4° ±2°) FAR (horizontal: 11.4° ±1°, vertical: 7.2° ±1°) Symbol Contrast: 20% |
READ RANGES (TYPICAL, WHITE ILLUMINATION)
| SYMBOLOGY |
NEAR DISTANCE ( CM [IN] )** |
FAR DISTANCE ( CM [IN] )**
|
| 13 MIL UPC |
5 [1.97] |
280 [100.24] |
| 5 MIL C39 |
9,5 [3.74] |
136 [53.54] |
| 10 MIL C39 |
6 [2.36] |
236 [103.54] |
20 MIL C39
|
8 [3.15]
|
589 [231.89]
|
55 MIL C39
|
20 [7.07]
|
1500 [590.55]
|
10 MIL QR
|
9 [3.54]
|
138 [54.33]
|
55 MIL QR
|
12 [4.72]
|
704 [277.16]
|
100 MILS C39 RFL
|
36 [14.17]
|
2900 [1141.73]
|
100 MILS C128 RFL
|
26 [10.24]
|
2250 [885.83]
|
* Depends on the width of the bar code (shorter bar codes can be read even at closer distances, while wider bar codes need to be further away). ** In darker ambient light conditions, the distance is reduced.
|
SYMBOLOGIES TYPE
| LINEAR |
Codabar, Code 11, Code 128, Code 2 of 5, Code 39, Code 93 and 93i, EAN/JAN-13, EAN/JAN 8, IATA Code 2 of 5,Interleaved 2 of 5, Matrix 2 of 5, MSI, GS1 Databar, UPC-A, UPC E, UPC-A/EAN-13 with Extended Coupon Code, Coupon GS1 Code 32(PARAF), EAN-UCC Emulation, GS1 Data Bar |
| 2D STACKED |
Codablock A, Codablock F, PDF417, MicroPDF417 |
| 2D MATRIX |
Aztec Code, Data Matrix, MaxiCode, QR Code, Chinese Sensible (Han Xin), Grid Matrix, Dot Code |
POSTAL
|
Australian Post, British Post, Canadian Post, China Post, Japanese Post, Korea Post, Netherlands Post, Planet Code, Postnet
|
Q :Are you manufacturer?
A: Yes, we are manufacturers.All of our products are fully patented, ID/MD design, hardware and software,mold,assembly are done by our own team.
Q1: Does the handheld can read QR code and common 1d bar codes?
A1: Yes, if choose 2d scan version, it can read both 1D common code and 2d codes such as QR, PDF417, Data Matrix, PDF417 code...
Q: Would you provide SDK for me?
A: Yes, we offer free SDK if you order sample.In addition, we also have support engineers to assist you with software development.
Q: What is the least order quantity (MOQ)?
A: We accept one unit for standard products.
Q: Can we get the free sample?
A: Sorry, generally we would not provide the free sample. If the customer confirm the specification and price, they can order the sample firstly for the testing and evaluation.
Q: Can i choose multiple function into 1 device?
A: Yes, you can choose multiple fuction into onedevice, Different functions depending on the product model,optional functions:RFID (LF/HF/UHF)1 Fingerprint/ Bar code scanner.
Q: How to order and pay?
A: We accept T/T (bank transfer), Alibaba online,Western Union 1 Trade Assurance
Q: What's Your Products Warranty?
A: We Offer 24 Months Warranty after shipment sent.
Q: Can I extend the warranty?
A: We offer a deferred warranty for up to 36 Months, and the price for the warranty extension is 10% up.
Q: How long it will take for delivery?
A: For production lead time around 3-10days depend on requirement, and shipping time by DHL/UPS/FEDEX/TNT, delivery time would around 3-5 working days. For some remote place, delivery time maybe a little bit longer.
Q:How to repair the device if any problem ?
A: We will provide technical support online to solve problem; If for the hardware problem , we couldsend the parts or components and teach customer to fit if they have technician or can also send backto us to fix it.
