| CPU |
ARM Cortex A73 Octa-core (2.0GHz)
|
|
| GPU |
ARM Mali-G72 MP3
|
|
| RAM | 8GB | |
| Internal Memory | 128GB | |
| External Memory |
Micro SD card ( T-FLASH card), max 256GB
|
|
| Main Camera |
13.0MP(AF) with flash led
|
|
|
Sub Camera
|
5.0MP
|
|
| Battery |
7800mAh (Replaceable battery)
|
|
| Display |
5.5 inch IPS/AFFS 1080*1920 FHD industrial 500cd/m2 Sunlight Readable
|
|
| Touch Panel |
Capacitive/frosted tempered film supports glove touch/spray/active capacitive pen
|
| SIM Card |
Nano sim card*2
|
| TF Card |
Micro SD card(T-FLASH card); max 256GB
|
| Headphone |
3.5mm (CTIA)
|
|
Charging interface
|
Type-C & 2pin pogo pin
|
| Data interface |
USB Type-C(OTG)*1
|
|
RS232(optinal)
|
RS232*1
|
| Gravity sensor | support |
|
Direction Sensor
|
support |
|
Magnetic Field Sensor
|
support |
|
Gyro sensor
|
support |
|
Rotation Vector
|
support |
|
Light-sensor
|
support |
|
Acceleration sensor
|
support |
|
Motion sensor
|
support |
| Charger | 5.0V 2A-10W |
| Navigation | GPS+Beidou+Glonass+AGPS+SBAS （EPO 2.5m） |
| Size | 195*98*22mm (L×W×H) |
| Weight | 460g |
| Color & Material | Black&Gray |
| Phone Call | GSM /WCDMA/CDMA 1X/VoLTE |
| 2G | GSM/CDMA 1X/EDGE/GPRS/WAP |
| 2G Band | GSM（B2/3/5/8） |
| 3G | WCDMA 3.75G (HSDPA+ 42.2Mbps, HSUPA+ 11.5Mbps),EVDO |
| 3G Band | WCDMA（B1/2/5/8）,Evdo: BC0/BC1 CDMA: BC0/BC1 |
| 4G | FDD: 150Mbps down, 50Mbps UP TDD: 150Mbps downlink , 50Mbps uplink |
| 4G Band | TD-LTE（B38/39/40/41）；FDD LTE（B1,B2,B3,B4,B5,B7,B8,B12,B17,B20,B28) |
| WI-FI | Dual-band (2.4GHz/5Ghz) single stream 802.11 a/b/g/n/ac |
| Bluetooth | 5.0 Low Energy (LE) |
| Shake-proof | 1-19Hz/1.0mm; 19-200Hz/1.0g |
| Dropproof /IK | MIL-STD-810G/Method516.6/Procedure IV & Touch Panel IK05 |
| Waterproof |
Class 7(IEC 60529)
|
| Dustproof |
Class 6 (IEC 60529)
|
| Reliability | MTBF>5000h；MTTR<0.5h |
| Operating temperature | -20°C to 55°C |
| Storage Temperature | -40°C to 88°C |
| RH |
5%RH-95%
|
| Operating Altitude | Max: 4,500 m（15,000 feet） |
| Certification |
3C/FCC/CE/ROHS/IP67 (IEC 60529)
|
| Language |
English, Spanish, Portuguese (Brazil), Portuguese (Portugal), Italian, German, Dutch, French, Polish, Romanian, Turkish, Russian, Arabic, Indonesian, Malay, Thai, Vietnamese, Hindi, Hebrew, Simplified, Chinese, Chinese Traditional, etc.
|
| OS | Android 10 / 11 |
| Warranty | 24 months |
| Package |
USB cable/Charger 5V 2A/Introduction manual/Screen protector/Packing box/Aircraft box/Toolkit(optional)/OTG x 1/SIM Card Ejector x 1
|
|
FUNCTION MODULES
|
|
Frequency
|
13.56MHz
|
|
Protocol standard
|
ISO14443A/B, ISO15693, NFC
|
|
Label standard
|
M1 (S50, S70), CPU, NFC
|
|
Read-write distance
|
2-5cm
|
|
Air interface protocol
|
EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C
|
|
Operating spectrum range
|
902Mhz – 928Mhz 865MHz – 868MHz (Optional) |
|
Output range
|
0-26bdm
|
|
Output accuracy
|
+/- 1dB
|
|
Output power level
|
+/- 0.2dB ,The label is sensitive and stable.
|
|
Reading distance
|
≥1.8m (E41 tag)
|
| Scanning engine |
E20 Barcode Module
|
| 2D |
QR Code, Micro QR, Data Matrix, PDF417, Micro PDF417, Aztec, Maxicode, Hanxin code,Dotcode, Composite.
|
| 1D |
Code 128 ( ISBT 128, AIM 128, GSI 128 ), EAN-13, EAN-8, UPC-E, UPC-A, ISBN, ISSN, Code11, Interleaved 2 of 5, Code39, Code93, Code32, Codabar, Matrix 2 of 5, Industrial 25, IATA25, MSI Plessey, GSI DataBar, Plessey, Febraban.
|
Q :Are you manufacturer?
A: Yes, we are manufacturers.All of our products are fully patented, ID/MD design, hardware and software,mold,assembly are done by our own team.
Q1: Does the handheld can read QR code and common 1d bar codes?
A1: Yes, if choose 2d scan version, it can read both 1D common code and 2d codes such as QR, PDF417, Data Matrix, PDF417 code...
Q: Would you provide SDK for me?
A: Yes, we offer free SDK if you order sample.In addition, we also have support engineers to assist you with software development.
Q: What is the least order quantity (MOQ)?
A: We accept one unit for standard products.
Q: Can we get the free sample?
A: Sorry, generally we would not provide the free sample. If the customer confirm the specification and price, they can order the sample firstly for the testing and evaluation.
Q: Can i choose multiple function into 1 device?
A: Yes, you can choose multiple fuction into onedevice, Different functions depending on the product model,optional functions:RFID (LF/HF/UHF)1 Fingerprint/ Bar code scanner.
Q: How to order and pay?
A: We accept T/T (bank transfer), Alibaba online,Western Union 1 Trade Assurance
Q: What's Your Products Warranty?
A: We Offer 24 Months Warranty after shipment sent.
Q: Can I extend the warranty?
A: We offer a deferred warranty for up to 36 Months, and the price for the warranty extension is 10% up.
Q: How long it will take for delivery?
A: For production lead time around 3-10days depend on requirement, and shipping time by DHL/UPS/FEDEX/TNT, delivery time would around 3-5 working days. For some remote place, delivery time maybe a little bit longer.
Q:How to repair the device if any problem ?
A: We will provide technical support online to solve problem; If for the hardware problem , we couldsend the parts or components and teach customer to fit if they have technician or can also send backto us to fix it.
